CYZ-A type explosion-proof self-priming centrifugal pump

Payment Type: L/C,T/T,D/P,Paypal,Money Gram,Western Union
Min. Order: 1 Set/Sets
Delivery Time: 15 Days

Basic Info

Model No.: BODA-122

Impeller Number: Single-Stage Pump

Working Pressure: High Pressure Pump

Influent Type of Impeller: Single Suction Pump

Position of Pump Shaft: Horizontal Pump

Pump Casing Combined: Verticaljoint Surface Pump

Mounting Height: Since Irrigation Centrifugal Pumps

Impeller: Open

Usage: Pump

Product Name: S Series Double Suction Pump

Additional Info

Packaging: wooden box

Productivity: 500

Brand: BODA

Transportation: Ocean,Land,Air

Place of Origin: china

Supply Ability: 500

Certificate: ISO9901

HS Code: 4101201190

Port: Tianjin,Qingdao,Shanghai

Product Description

CYZ-A type explosion-proof self-priming centrifugal pump 2

CYZ-A type explosion-proof self-priming centrifugal pump 4

CYZ-A type explosion-proof self-priming centrifugal pump product features

      The pump is a self-priming centrifugal pump. The self-priming centrifugal pump has the advantages of simple structure, convenient operation, stable operation, easy maintenance, high efficiency, long service life and strong self-priming capability. There is no need for a bottom valve in the pipeline, and it is only necessary to ensure that the pump body has a certain amount of oil before the work. When used on a tanker or water delivery vessel, it can double as a sweeping pump, and the sweeping effect is good.

The self-priming centrifugal pump is made of high-quality materials. The seal is made of hard alloy mechanical seal. It is durable. It does not need to install safety valve for the discharge pipe. The suction pipe does not need to install the bottom valve, thus simplifying the pipeline system. It also improved working conditions.

YZ-A type explosion-proof self-priming centrifugal pump instructions

(1) Preparation and inspection before starting:

1. This series of oil pumps are lubricated with high-quality calcium-based butter and No. 10 oil according to the working condition of the pump. If the pump is lubricated with grease, the grease should be regularly added to the bearing housing, and the oil-lubricated pump should be used. If there is not enough, it will be added.

2. Check whether the liquid in the pump casing is higher than the upper edge of the impeller. If it is insufficient, the liquid can be injected directly into the pump body from the filling port on the pump casing. It should not be started in the case of insufficient liquid storage. The pump does not work properly and is susceptible to damage to the mechanical seal.

3. Check if the rotating parts of the pump are stuck or bumped.

4. Check the nut of the pump body and the nuts at the joints for looseness.

5. Check the coaxiality or parallelism of the pump shaft and the motor shaft.

6. Check the inlet pipe for leaks. If there is a leak, you must try to eliminate it.

7. Open the valve in the suction line and slightly open (not fully open) the outlet control valve.

(2) Stop the pump

1. First, the gate valve on the discharge line must be closed.

2. Stop the pump from rotating.

3. In the cold season, the liquid in the pump body and the water in the cooling chamber of the bearing body should be emptied to prevent cracking of the machine parts.
