Heavy Duty Mining Sand Gravel Dredging Slurry Pump
Model No.: AH BH
Working Pressure: High Pressure Pump
Position Of Pump Shaft: Horizontal Pump
Material: A05 A07 A49
Drive Type:: CV, DC, Zv, Cr
Color: As Your Requirement
Package: In Woodenc Case Or As Your Requirement
Power: Electric Or Diesel
Product Name: Martime Application Slurry Pump
Packaging: In Wooden case or as your requirement
Place of Origin: Shijiazhuang
Supply Ability: 300 sets per month
HS Code: 8413709990
BG/BGH gravel pump
Long service life,high efficiency
Good quality with favourable price
High hardness,anti-wear alloy cast iron
Sand suction pump :
Constructin of this pump is of single casing connected by means of clamp bands and
wide wet passage. The wet parts are made of Ni hard and high chromium abrasion
resistance alloys. The discharge direction of pump can be oriented in any direction of
360 degree. This type of pump possesses the advantages of easy installation and
operation, good performance of NPSH and abrasion resistance.
Sealing forms: packing gland, expeller seal, mechanical seal.
Driving type: V belt drive, hydraulic coupling drive, fluid coupling drive, frequency
conversion drive devices, thyrister speed regulation ect.
They are suitable for delivering slurries in mining, explosive sludge in metal melting,
grudging in dredger and course of river, and other fields. Type BGH pumps are of high
1) Cantilevered, horizontal, centrifugal, one stage, single casing gravel (sand) pump
2) High head, large capacity, high efficiency.
3) Good NPSH performance.
4) Widely application: they are designed for handling more abrasive with solids slurries
in the river dredging, Sand reclamation, Sugar beet , explosive sludge in metal melting,
grudging in dredger and course of river and other fields.
5) Long bearing life: The bearing assembly is with large diameter shaft and short overhang.
6) Wear resistant wet parts: the wet parts are made of Ni hard and high chromium
abrasion resistance alloys. (more than 26% Chrome alloy).
7) Simple maintenance throat bush: the mating face of the throat bush is tapered,
so the wear is reduced and removal is simple.
8) Easy adjustment of impeller: An impeller adjustment mechanism is provided
below the bearing housing.
9) Centrifugal seal, mechanical seal and packing seal are available.
10) The pump can be directly matched with either motor or diesel engine
It can be equipped with diesel engines or be equipped with motor driven directly. It has the advantages of working stability, little vibration, low noise and low hydraulic loss, high efficiency, low fuel consumption and small size, light weight, simple structure, easy maintenance.
