High Efficiency Gravel Dredging Mud Sand Pump

Payment Type: L/C,T/T,Western Union
Incoterm: FOB,CFR,CIF
Min. Order: 1 Set/Sets
Delivery Time: 30 Days

Basic Info


Model No.: 6/4D-G

Impeller Number: Single-Stage Pump

Working Pressure: Low Pressure Pump

Influent Type of Impeller: Single Suction Pump

Position of Pump Shaft: Horizontal Pump

Pump Casing Combined: Horizontal Split Pumps

Mounting Height: Suction Centrifugal

Impeller: Closed

Usage: Pumps

Application: Mining, Steel Factory, Sand Transportation

Material:: A05, A07, A49

Theory:: Centrifugal Pump

Shaft Seal:: Packing Seal, Mechanical Seal, Expeller Seal

Application 1:: Mine And Miner Processing

Medium Concentration: Max Cv Or CW 80% At Heavy Duty

Fuel:: Electric Or Fuel Driven By Engine

Power:: Electric

Usage:: Slurry, Sludge, Mud And Dirty Water In Mining

Pump Name: Horizontal Centrifugal Heavy Duty Mining Slurry Pu


Additional Info


Packaging: In wooden case

Productivity: 500 sets per month

Brand: Boda

Transportation: Ocean,Land,Air

Place of Origin: China

Supply Ability: 300 sets per month

Certificate: ISO90001

HS Code: 8413709990

Port: Xingang,Horgos,Yunnan


Product Description

Features:

1. dredge pump suitable for dredging ship:
The structure of 200WN-500WN type pumps are single-casing, single-stage, single-suction, cantilever and horizontal. According to the connection with the gear box, two structures can be offered: self-carrying bracket and pump-box assembly. The lubrication for the bracket is grease or thin oil.
The structure of 600WN-1000WN type pumps are double-casing, single-stage, single suction, cantilever and horizontal. It has self-carrying bracket. Lubrication is forced thin oil lubricating. The double-casing design can ensure the liner can work till it is worn out, and if the liner crack, water can not enter into the pump.

2. Easy to Disassembly and Installation, Convenient Maintenance:
WN type pump adopts front-disassembly structure in favor of easy disassembly and maintenance. Also it is equipped with special disassembly tools for each different part according to each parts features.
The standard trapezoidal quadruple thread is adopted to connect the impeller and shaft, which not only transmits strong torque but also is easy to disassembly.

3. Good Performance on NPSH:
The good NPSH performance of WN type pump ensures the strong suction ability as well as deeper dredging depth and denser dredging concentration.

4. Good Wear-resistant Performance, Long Service Time of Wet Parts:
Wet parts of this kind of dredging pump-impeller, liner and front & back liner plate are adapted anti-wear cast iron alloy whose hardness is more than 58HRC, who has both strong anti-attack feature and higher resistance wear and resistance abrasion features.

5. Reliable Shaft Sealing Without Leakage:
The shaft of 200-500WN dredging pump uses the mechanical sealing or stuffing sealing or mechanical-stuffing compound sealing.
The shaft of 600-1000 WN dredging pump adopts spiral sleeve L (shape) rubber sealing device that consists of three L sealing ring and one special thread shaft sleeve
Structure drawing:


Type
Capacity (m 3 /h) Head (m) Speed (r/min) Efficiency (%) NPSHr(m) Inlet Dimeter (mm) Outlet Diameter   (mm) Max.Diameter of Flowd Parti   (mm) weight(kg)
200WND 600~800 20~40 700~900 60~65 <4.5 250 200 178 2500
200WN 750~1000 40~65 700~850 70~72 <4 250 200 180 3000
250WND 950~1100 20~40 500~700 65~70 <4 300 250 220 3000
250WN 1100~1300 40~65 500~650 70~74 <4 350 250 144 3513
300WND 1500~1800 20~40 400~600 65~68 <4 350 300 241 6000
300WN 1800~2200 40~65 400~550 74~78 <4 450 300 241 7000
350WN 2600~3000 40~65 400~550 74~78 <4.5 450 350 245 7300
400WN 2800~3200 20~40 400~550 74~78 <4.5 450 400 250 7500
450WN 3200~3850 40~67 350~500 76~80 <4.5 600 450 254 7850
500WNQ 3600~4200 20~40 220~320 72~75 <4.8 600 500 330 8000
500WN 4500~5500 40~65 350~450 78~80 <4.8 650 500 250 11300
600WN 7000 62 470 80 <6 700 600 220 30000
600WNQ 7000 30 380 83 <6 700 600 220 16000
700WN 10000 85 380 85 <6 760 700 280 45000
700WNQ 10000 28 280 85 <6 760 700 280 21000
800WN 12500 59 349 81 <6 800 750 300 40000
800WNQ 12500 32 258 81 <6 800 750 300 23000
800WND 12500 32 258 81 <6 800 750 300 23000
850WN 14400 70 330 85 <6 900 850 320 65000
900WN 16000 30 175 85 <6 1000 900 340 80000
1000WN 16000~25000 23~76 181~290 85~87 <6 1200 1000 350 121000
